Application

PW series is a new generation automatic booster pump can supply constant water.

The integrated pump includes motor, tank, pressure switch, flow sensor in one unit that is more reliable and easy to operate.

-It's suitable for both cold and hot water, can be widely used in household pressure boositing from above ground water tanks or below water sources.

Pump

Electrophoretic for pump body & bracket

Mechanical seal (graphite to ceramic)

Brass impeller

AISI 304 stainless steel welding shaft

Max.Liquid temperature:+80℃

Max.suction head:+8m

Motor

C&U bearing

Motor with copper winding

Built-in thermal protector for single phase

Insulation class: F

Ingress Protection: IP44

Max.ambient temperature:+40℃

Wide range voltage design(160V~230V)

Other voltages or 60 Hz be available at request
