Application

Can be used to transfer clean water or other liquids similar to water in physical and chemical properties.

Suitable for industrial use and urban water supply,pressure boosting for high buildings and fire fighting,garden irrigation long-distance water transfer,heating ventilation ans air controlling,circulation and pressure boosting for cold and hot water,and supporting equipment etc.

Pump

Electrophoretic for pump body & bracket

Mechanical seal (graphite to ceramic)

①Brass impeller ②PPO impeller

AISI 304 stainless steel welding shaft

Max.Liquid temperature:+60℃

Max.suction head: +8m

Motor

C&U bearing

Motor with copper winding

Built-in thermal protector for single phase

Insulation class: F

Ingress Protection:IP44

Max.ambient temperature:+40℃

Wide range voltage design(160V~230V)

Other voltages or 60 Hz be available at request
