Application
1. Subvert the appearance design of the industry and lead the industry trend.
2. Full lift design, can be used with confidence under any load. The motor has a built-in protector with burn-in protection function.
3. Use C-grade all-copper enameled wire, with high temperature resistance of 200°C.
4. Oil-flooded motor, diving depth up to 200m.
5. Use 304# stainless steel welded shaft, stainless steel 304 screws, stainless steel 304 barrel, which is corrosion-resistant and more durable.
6. The overall floating impeller structure design reduces the starting torque and can pass through small impurities such as fine sand.
7. Plug-in cable, easy to replace.
8. Pin-type structure, easy to disassemble.
Conditions of Use
1. The temperature does not exceed 40℃
2. The solid content (by weight) does not exceed 0.01%
3. The acid-base pH value is 6.5~8.5
4. The combined hydrogen sulfide content does not exceed 1.5mg/, and does not contain any oil. (lf used in deep wells, the wellbore should be kept vertical and no two-way bends are allowed)
Application
1. Subvert the appearance design of the industry and lead the industry trend.
2. Full lift design, can be used with confidence under any load. The motor has a built-in protector with burn-in protection function.
3. Use C-grade all-copper enameled wire, with high temperature resistance of 200°C.
4. Oil-flooded motor, diving depth up to 200m.
5. Use 304# stainless steel welded shaft, stainless steel 304 screws, stainless steel 304 barrel, which is corrosion-resistant and more durable.
6. The overall floating impeller structure design reduces the starting torque and can pass through small impurities such as fine sand.
7. Plug-in cable, easy to replace.
8. Pin-type structure, easy to disassemble.
Conditions of Use
1. The temperature does not exceed 40℃
2. The solid content (by weight) does not exceed 0.01%
3. The acid-base pH value is 6.5~8.5
4. The combined hydrogen sulfide content does not exceed 1.5mg/, and does not contain any oil. (lf used in deep wells, the wellbore should be kept vertical and no two-way bends are allowed)
