Application

1. Subvert the appearance design of the industry and lead the industry trend.

2. Full lift design, can be used with confidence under any load. The motor has a built-in protector with burn-in protection function.

3. Use C-grade all-copper enameled wire, with high temperature resistance of 200°C.

4. Oil-flooded motor, diving depth up to 200m.

5. Use 304# stainless steel welded shaft, stainless steel 304 screws, stainless steel 304 barrel, which is corrosion-resistant and more durable.

6. The deep well pump adopts a single-stage floating impeller design to reduce starting torque and extend service life.

7. Plug-in cable, easy to replace.

8. Pin-type structure, easy to disassemble.

Conditions of Use

1. The temperature does not exceed 40℃

2. The solid content (by weight) does not exceed 0.01%

3.The acid-base pH value is 6.5~8.5

4.The combined hydrogen sulfide content does not exceed 1.5mg/, and does not contain any oil. (lf used in deep wells, the wellbore should be kept vertical and no two-way bends are allowed)
