    Application Limits

    Maximum liquid temperature +40℃

    PH level from 6.5-8.5

    Maximum sand contentis 0.1%

    Passage of suspended solids up to 0.2mm

    Powerf requency is 50Hz.

    Nominal voltage is 380VAC for three phase with the range from-10% to 10%.

    Immersion depth from0.5m-5m


    Advantages Features

    Wear-resistant whole cast iron parts design.

    Compact structure,easy to use.

    High quality double sides mechanical sealing to be reliable operating.

    • 0.00
      0.00
Product Description

Application Limits

Maximum liquid temperature +40℃

PH level from 6.5-8.5

Maximum sand contentis 0.1%

Passage of suspended solids up to 0.2mm

Powerf requency is 50Hz.

Nominal voltage is 380VAC for three phase with the range from-10% to 10%.

Immersion depth from0.5m-5m


Advantages Features

Wear-resistant whole cast iron parts design.

Compact structure,easy to use.

High quality double sides mechanical sealing to be reliable operating.
