Application

Small electrica irgation and drainage equipments. Particularly applied in urban well water pumping,field irrigation and drainage.Gerden irrigation and household water supply,as well as drainage of industrial accumulated water,water supply and drainage for construction,livestock breeding,etc.

Limites

Maximum liquid temperature:+40℃

PH value:6.5-8.5

Maximum sand content is 0.1%

Max immersion depth :5m

Motor

Power frequency is50HZ(or 60HZ)

Frequency/pole:50Hz/2

Insulation class:F

Protection class :IPX8

Bearing :Ball type

Mechanicalseal:Double-end mechanical seals

Voltage range :220V single phase, 380V Three phase

Castiron pump body

Aluminum motor housing
